Main Features:
Compatible with all HD-CVI,HD-TVI,HD-AHD
Up to 450m for 720P CVI camera
Up to 250m for 1080P CVI camera
Up to 250m for 720P/1080P TVI camera
Up to 320m for 720P AHD camera
NTSC,PAL,and SECAM video formats
No power required
60dB cross talk and noise immunity
Compact size and easy installation
Built-in transient suppression protectio
Technical Specifications:> Frequency response:DC to 60Mhz
> Attenuation:0.5dB type
> CMRR:60dB
> Surge protection:4KV
EDS:8KV
> Connectors:Male BNC and "Press -fit "terminal blocks
> Impedance BNC:75 OHMs
Terminal:100 OHMs
> Working temperature:-10~+70 Degree
> Storage temperature:-30~+70 Degree
> Humidity:0~95 %
> Dimension:39 x 16 x 19mm(excluding connectors)
> Material: ABS plastic
